Pre-grinding System (CKP mill)

  1. High operation availability
  2. Stable operation
  3. Less maintenance cost

Pre-grinding system with CKP vertical type mill is applied for increasing capacity and reducing power consumption of existing ball mill grinding system.

The capacity can be increased up to double (100%). Also CKP mill achieves energy saving of 30 % at most compared with conventional ball mill system.

Supply List

Features

  1. High operation availability

    Since the life time of wearing parts of CKP mill is long, continuous operation is realized.

  2. Stable operation

    Change of particle size distribution of feed material does not deteriorate grinding capacity substantially.

  3. Less maintenance cost

    Since the life time of wearing parts of CKP mill is long, the frequent maintenance is not required.

Example of Flow

Pre-grinding systemcapacity increase up to 50%

Semi finish grinding systemcapacity increase up to 100%
